GPS Vehicle Tracker
Features:
- Waterproof (IP66)
- Tracking by SMS/GPRS (TCP/UDP)
- Tracking regularly
- Support setting 3 authorized cell phone numbers
- Power saving mode
- Authorized number
- Real time tracking
- Geo-fence
- Over speed alarm
- Vibration alarm
- Low battery alarm
- No GPS signal alarm
- Data Logger
- 2 digital outputs, 3 digital inputs and 2 analog inputs
- External power connected/disconnected alarm
This information only is for informational purposes only, Plaspy does not have relationship with the device's manufacturer, for more information check the manufacturer's website or user manual.
Set Up GMT-368SG
Country
Carrier
APN
User
Password
To set the tracker send the following commands by SMS messages, the sample setup the device password is 5hKBdm, this password is the default
Type the IMEI number
-
Set the device ID
M5hKBdm,22,{{('XXXXXXXXXXXXXXX' + imei.substring(0,15)).slice(-15)}} -
Set the operator APN
M5hKBdm,23,{{apn}},{{apnu}},{{apnp}}
-
Set the update interval 60 seconds
M5hKBdm,25,60 -
Set the GPRS server
M5hKBdm,24,56 54.85.159.138,8888 -
Enable GPRS mode
M5hKBdm,21,2
